- Microprocessor-based SAT- Automatic environmental test circuitry- Built-in door or window contactThe DS1109i Detector uses microprocessor-based sound analysis technology (SAT) to listen for the specific frequencies associated with breaking glass. It can be used to detect breakage of plate, tempered, laminated and wired glass types. A built-in environmental test feature alerts the installer of false alarm hazards in harsh environments. It is specially designed to mount on door or window frames. A built-in magnetic contact allows monitoring of a door or window opening.
- Up to 7.6 m (25 ft) mounting height- 360° x 20 m (70 ft) diameter pattern- Fully-adjustable optical arrays for coverage customization- Hinged chassis and base plate for easy installation- High-efficiency LED and light-pipe system for easy walk testingThe DS9371 TriTech detector can be used on ceilings as high as 7.6 m (25 ft). The combination of passive-infrared (PIR) detection, microwave detection, and advanced signal processing techniques allows TriTech detectors to rapidly respond to human targets without triggering false alarms from other sources. With three separate fully-adjustable PIR sections, coverage can be customized for specific areas at all mounting heights.
Provides PIR, 12 m x 12 m (40 ft x 40 ft) coverage, utilizing two PIR sensors in one detector.
Mounts a seismic detector within the floor. Weighs 2.08 kg (4.5 lb). Requires a base area of at least 30 cm x 30 cm (12 in. x 12 in.) and a depth of 80 cm (31 in.).
- 24-hour surveillance of vault walls and doors, safes, night safes, and automatic teller machines- Sensitivity settings using DIP switches- SENSTEC sensor and signal processing system based on microcontrollers- Low-profile design
Seismic detector with 4m operating radius on concrete and 50m monitoring areaWhen cutting and drilling through materials such as concrete, steel, or synthetic reinforcements, deviations from the structures' normal vibration pattern ensue. The SENSTEC sensor converts vibration deviations into electrical signals. The digital processing in the seismic detector analyzes the signals and compares them to a frequency range typical of tools used to break into safes, night safes etc. If the signals fall within this frequency range, the seismic detector transmits an alarm via a relay contact.
- 24-hour surveillance of vault walls and doors, safes, night safes, and automatic teller machines- Sensitivity settings using DIP switches- SENSTEC sensor and signal processing system based on microcontrollers- Low-profile designSeismic detector with 5m operating radius on concrete and 80m monitoring area.When cutting and drilling through materials such as concrete, steel, or synthetic reinforcements, deviations from the structures' normal vibration pattern ensue. The SENSTEC sensor converts vibration deviations into electrical signals. The digital processing in the seismic detector analyzes the signals and compares them to a frequency range typical of tools used to break into safes, night safes etc. If the signals fall within this frequency range, the seismic detector transmits an alarm via a relay contact.
Bosch B10R. Width: 12.5" (318 mm), Depth: 2.99" (76 mm), Height: 14" (356 mm)
The PVA-4R24 24 Zone Router is a zone extension for the PAVIRO system. The PVA-4R24 adds 24 zones 20 GPIs 24 GPOs and 2 control relays to the system and is controlled and supervised via the CAN bus by the PVA-4CR12 (Controller). Up to 20 external routers can be connected to one controller. One router can handle up to 4000 W speaker load. The maximum load of one zone is 500W.The zone indicator lights on the front indicate the current status of every zone:• Green: Zone in use for non emergency purpose• Red: Zone in use for emergency purpose• Yellow: Zone fault detected• Off: Zone in idle condition
MFR: Netgear, Inc
Qty: 1
Part #: GS105NA
