Display |
---|
LED backlight | Yes |
Display number of colours | 1.7 billion colors |
Panel type | IPS |
LED backlighting type | Direct-lit LED |
Touchscreen | No |
Active display area (W x H) | 85 x 47.8" (2158.8 x 1214.3 mm) |
Display technology | LCD |
Display diagonal | 98" |
Display resolution | 3840 x 2160 pixels |
Display brightness | 500 cd/m² |
HD type | 4K Ultra HD |
Contrast ratio (typical) | 8000:1 |
Viewing angle, horizontal | 178° |
Viewing angle, vertical | 178° |
Pixel pitch | 0.0221 x 0.0221" (0.562 x 0.562 mm) |
Native refresh rate | 60 Hz |
Ports & interfaces |
---|
USB connector type | USB Type-A |
DisplayPorts out | 1 |
USB port | Yes |
DisplayPorts in | 2 |
HDMI version | 2.0 |
PC Audio out | Yes |
DisplayPorts quantity | 3 |
Ethernet LAN | Yes |
HDMI ports quantity | 3 |
Ethernet LAN data rates | 10,100 Mbit/s |
DVI port | No |
Ethernet LAN (RJ-45) ports | 2 |
RS-232 interface | Yes |
USB version | 2.0 |
HDMI input ports quantity | 2 |
HDMI output ports quantity | 1 |
USB 2.0 Type-B ports quantity | 1 |
Audio |
---|
Built-in speaker(s) | No |
Design |
---|
Product design | Digital signage flat panel |
Placement supported | Indoor |
Orientation | Horizontal/Vertical |
Product colour | Black |
Panel mounting interface | 600 x 400 mm |
VESA mounting | Yes |
Performance |
---|
Purpose | Corporate |
Power |
---|
Power consumption (max) | 590 W |
Power consumption (typical) | 340 W |
Power consumption (standby) | 0.5 W |
AC input voltage | 100 - 240 V |
Weight & dimensions |
---|
Width (with stand) | 75.9" (1927.6 mm) |
Height (with stand) | 43.3" (1099.1 mm) |
Depth (with stand) | 3.28" (83.2 mm) |
Display width | 75.9" (1927.6 mm) |
Display depth | 3.32" (84.3 mm) |
Display height | 43.3" (1099.1 mm) |
Display weight | 147.7 lbs (67 kg) |
Packaging data |
---|
Package width | 82.3" (2090 mm) |
Package depth | 8.86" (225 mm) |
Package height | 48.2" (1225 mm) |
Package volume | 98700 cm³ |
Remote control included | Yes |
Remote control type | RU-M125 |
Cables included | AC, HDMI |
Packaging content |
---|
Remote control included | Yes |
Remote control type | RU-M125 |
Cables included | AC, HDMI |
Operational conditions |
---|
Operating altitude | 0 - 118110.2" (0 - 3000 m) |
Non-operating altitude | 0 - 480000" (0 - 12192 m) |
Operating relative humidity (H-H) | 20 - 80% |
Storage temperature (T-T) | -20 - 60 °C |
Storage relative humidity (H-H) | 10 - 80% |
Technical details |
---|
VESA mounting | Yes |
USB connector type | USB Type-A |
Panel type | IPS |
DisplayPorts out | 1 |
DisplayPorts in | 2 |
LED backlighting type | Direct-lit LED |
Other features |
---|
USB connector type | USB Type-A |
Panel type | IPS |
DisplayPorts out | 1 |
DisplayPorts in | 2 |
Width (with stand) | 75.9" (1927.6 mm) |
USB 2.0 ports quantity | 2 |
Power consumption (max) | 590 W |
PC Audio out | Yes |
Operating altitude | 0 - 118110.2" (0 - 3000 m) |
Non-operating altitude | 0 - 480000" (0 - 12192 m) |
Height (with stand) | 43.3" (1099.1 mm) |
Display technology | LCD |
Depth (with stand) | 3.28" (83.2 mm) |
